Specification
SPECIFICATION
| MODEL | INSTA INGRAZE 53 |
| OPERATING VOLTAGE | 24V DC |
| POWER CONSUMPTION | 48W/1045mm |
| LED TYPE | High Power LED |
| COLOUR TEMP OPTION | 2700K, 3000K, 3500K, 4000K, 5000K, Tunable White, RGB,RGBW |
| CRI | 90min, 80min |
| PRODUCT EFFICACY | 77lm/W@3000K |
| FULL WIDTH AT HALF MAXIMUM (OPTICS) | 10°, 8°*15°, 8°*30° , 10°*50°, 20°*40°, 25°, 45°, 60° |
| MATERIAL | Aluminum + Stainless Steel 316L + Tempered Glass |
| PROTECTION | IK10 |
| AMBIENT OPERATING TEMPERATURE | -20°C ~ +55°C |
| STORAGE TEMPERATURE | -25°C ~ +60°C |
| LIFETIME | 50,000 hours/L70 at 25°C |
| DIMENSIONS | 1045(L)*55(W)*80(H)mm 345/545/mm ETO available |
| CABLE LENGTH | 300mm |
| CONTROL SYSTEM | ON/OFF. DMX, 0-10V Dim |
| MOUNTING TYPE | Recessed |
| IP RATING | IP67, IK10 |
