Specification
SPECIFICATION
| MODEL | INSTA FLEX GRAZE |
| OPERATING VOLTAGE | 24V DC |
| POWER CONSUMPTION | 5W/Unit, 8 Units Per Meter |
| LED TYPE | High Power LED |
| COLOUR TEMP OPTION | 2700K, 3000K, 4000K, 5000K, Tunable White, RGBW |
| CRI | 80min |
| PRODUCT EFFICACY | 76 lm/W@3000K |
| FULL WIDTH AT HALF MAXIMUM (OPTICS) | 10°*50°, 20°*40°, 35°, 45°, 60° |
| MATERIAL | Aluminum + Tempered Glass |
| AMBIENT OPERATING TEMPERATURE | -20°C ~ +55°C |
| STORAGE TEMPERATURE | -25°C ~ +60°C |
| LIFETIME | 50,000 hours/L70 at 25°C |
| DIMENSIONS | 125(L)*50(W)*58(H)mm, 125(L)*50(W)*116(H)mm (With Bracket) |
| CABLE LENGTH | 150mm |
| CONTROL SYSTEM | ON/OFF, DMX, 0-10V Dim |
| MOUNTING TYPE | Surface |
| IP RATING | IP66 |
